5-42 Chapter 5: BIOS setup
5.8 Monitor menu
The Monitor menu displays the system temperature/power status, and allows you
to change the fan settings.
CPU1 Temperature 60.0ºC/140.0ºF
CPU2 Temperature 54.5ºC/130.1ºF
TR1 Temperature 26.8ºC/80.2ºF
TR2 Temperature 27.0ºC/80.6ºF
FRNT FAN1 Speed 7031 RPM
FRNT FAN2 Speed 3948 RPM
FRNT FAN3 Speed 4005 RPM
FRNT FAN4 Speed 7105 RPM
FRNT FAN5 Speed 7142 RPM
FRNT FAN6 Speed 3580 RPM
FRNT FAN7 Speed 3452 RPM
+VTT_CPU +1.044 V
VCORE1 +0.960 V
VCORE2 +0.962
+VDDQ_AB_CPU1 +1.510 V
+VDDQ_CD_CPU1 +1.526 V
+VDDQ_EF_CPU2 N/A
+VDDQ_GH_CPU2 N/A
+5VSB +4.921 V
+5V +5.036 V
+12V +11.592 V
+3.3V +3.276 V
VBAT +3.168 V
+3.3VSB +3.234 V
CPU 1/2; MB; TR1/TR2 Temperature [xxxºC/xxxºF]
The onboard hardware monitor automatically detects and displays the CPU and
motherboard component temperatures. Select Ignore if you do not wish to display
the detected temperatures.
FRNT FAN1–7 Speed; [xxxx RPM] or [Ignore] / [N/A]
The onboard hardware monitor automatically detects and displays the speed of
CPU fans, front fans, and rear fan in rotations per minute (RPM). If the fan is not
connected to the motherboard, the field shows N/A.
+VTT_CPU Voltage, VCORE1/2 Voltage, +VDDQ_AB_CPU1
Voltage, +VDDQ_CD_CPU1 Voltage, +VDDQ_EF_CPU2 Voltage,
+VDDQ_GH_CPU2 Voltage, +5VSB Voltage, +5V Voltage , +12V
Voltage, +3.3V Voltage, VBAT Voltage, +3.3VSB Voltage
The onboard hardware monitor automatically detects the voltage output through
the onboard voltage regulators.
FAN Speed Control [Generic Mode]
Allows you to configure the ASUS Smart Fan feature that smartly adjusts the fan
speeds for more efficient system operation.
Configuration options: [Generic Mode] [High Speed Mode] [Full Speed Mode]
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Server Mgmt Event Logs Boot Monitor Security Tool Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
Disable: Voltage monitor.
Enabled: Temperature monitor.
