ASUS RS161-E5/PA2 4-3
Layout contents
Jumpers Page
1. Clear RTC RAM (CLRTC1) 4-5
2. Gigabit LAN1 controller setting (3-pin LAN1_EN1, LAN2_EN1) 4-6
3. VGA Graphics controller setting (3-pin VGA_EN1) 4-6
4. Fan control setting (3-pin FAN_SEL1) 4-7
5. Force BIOS recovery setting (3-pin RECOVERY1) 4-8
Internal connectors Page
1. Floppy disk drive connector (34-1 pin FLOPPY1) 4-8
2. IDE connectors (40-1 pin PRI_IDE1, SEC_IDE1) 4-8
3. Serial ATA connectors (7-pin SATA1, SATA2, SATA3, SATA4) 4-9
4. Hard disk activity LED connector (4-pin HDLED1) 4-10
5. USB connectors (10-1 pin USB34) 4-10
6. Front and rear fan connectors
(4-pin FRNT_FAN1/2/3/4, REAR_FAN1/2/3/4/5/6)
4-11
7. Serial port connectors (10-1 pin COM2) 4-11
8. ATX power connectors (24-pin ATXPWR1, 8-pin ATX12V1) 4-12
9. Power supply SMBus connector (5-pin PSUSMB1) 4-12
10. LPC debug card connector (14-1 pin LPC1) 4-13
11. Auxiliary panel connector (20-2 pin AUX_PANEL1) 4-14
12. System panel connector (20-1 pin PANEL1) 4-15
Onboard LED Page
1. Standby Power LED 4-4
2. CPU warning LED (CPU_WARN1) 4-4
3. Memory warning LED (MEM_WARN1) 4-4
