2-9 ASUS RS161-E5/PA2
2.3.2 Memory Configurations
You may install 256 MB, 512 MB, 1 GB, 2, or 4 GB registered ECC DDR2 DIMMs
into the DIMM sockets using the memory configurations in this section.
• For dual-channel configuration, the total size of memory module(s) installed
per channel must be the same for better performance.
Single CPU:
DIMM_A1=DIMM_A2=DIMM_B1=DIMM_B2;
DIMM_A3=DIMM_A4=DIMM_B3=DIMM_B4
Dual CPU:
DIMM_A1=DIMM_A2=DIMM_B1=DIMM_B2=
DIMM_C1=DIMM_C2 =DIMM_D1=DIMM_D2;
DIMM_A3=DIMM_A4=DIMM_B3=DIMM_B4=
DIMM_C3=DIMM_C4 =DIMM_D3=DIMM_D4
• Always install DIMMs with the same CAS latency. For optimum
compatibility, it is recommended that you obtain memory modules from the
same vendor.
A1 B1 A2 B2 A3 B3 A4 B4
CPU1 SingleChannel •
Dual Channel • •
• • • •
• • • • • •
• • • • • • • •
C1 D1 C2 D2 C3 D3 C4 D4
CPU2 Single Channel •
Dual Channel • •
• • • •
• • • • • •
• • • • • • • •
Memory population table
