Chapter 6: RAID Configuration
6-4
6.2.2
Entering the NVIDIA
®
RAID Utility
To enter the NVIDIA
®
RAID Utility:
1. Restart the computer.
2. During POST, press
The SATA ports are called channels that are associated with adapters. The first
digit in the Location field defines the adapter that the SATA port is associated with.
The 2nd digit defines the channel. The M field, That are used to specify Master or
Slave, is obsolete.
At the bottom section of the screen are the navigation keys. These keys allow you
to move through and select menu options.
[ESC] QUIT [F6] Back [F7] Finish [TAB] Navigate [↑↓] Select [ENTER] Popup
The navigation keys vary depending on the menu level or option.
[ESC] QUIT [F6] Back [F7] Finish [TAB] Navigate [↑↓] Select [ENTER] Popup
RAID Mode:
Striping
Striping Block:
Optimal
Free Disks
Array Disks
Loc Disk Model Name
Loc Disk Model Name
1.0.M XXXXXXXXXXXXXXXXXX
1.1.M XXXXXXXXXXXXXXXXXX
[→] Add
2.0.M XXXXXXXXXXXXXXXXXX
2.1.M XXXXXXXXXXXXXXXXXX
[←] Del
NVIDIA RAID Utility Mar 23 2006
- Define a New Array -
