6-7 ASUS RS161-E5/PA2
6.2.4 Rebuilding a RAID set
To rebuild a RAID set:
1. From the Array List, use the up or down arrow keys to select the RAID set
you want to rebuild, then press . The RAID set details appear.
2. Press .
3. Use the up or down arrow keys to select a the RAID set you want to rebuild,
then press . A confirmation message appears.
4. Press to start rebuilding the
array, or to cancel. The Array
List screen displays the RAID set
after rebuilding.
[↑↓] Select [F6] Back [F7] Finish
Array 1 : NVIDIA MIRROR XXX.XXG
- Array Detail -
RAID Mode: Striping
Striping Width: 1 Striping Block: 64K
Adapt Channel M/S Index Disk Model Name Capacity
2 1 Master 0 XXXXXXXXXXXXXXXXX XXX.XXGB
1 0 Master 1 XXXXXXXXXXXXXXXXX XXX.XXGB
[Ctrl-X]Exit [↑↓]Select [B]Set Boot [N]New Array [ENTER]Detail
NVIDIA RAID Utility Mar 23 2006
- Array List -
Boot Id Status Vendor Array Model Name
Yes 4 Healthy NVIDIA STRIPING XXX.XXG
Yes 3 Healthy NVIDIA MIRRORING XXX.XXG
Rebuild array?
[Enter] OK [Esc] Cancel
