4 SPECIFICATIONS
12V Power Supply
: 8-20V
12V Max. power
: 0.6W
Relay contacts
: Sub D-9 connector, galvanic isolated
Relay contacts rating
: 60VDC or 30VAC max
Current 0.5A max (50VA or 30W max)
Shutdown : Connect to GND or 12V Power supply pin only
Operating temp.
: 0 ~ +40°C
Storage temp.
: max. 60°C
*NOTICE!
Although the Relay Card output contacts are voltage free, they should not be connected to any mains
connected circuit. The outputs are not designed to switch AC loads directly. The shutdown input has been
designed to be driven by dry contact outputs only.
Do not attempt to power external devices using the 12V signal (pin 9)
Use reinforced isolation to the mains for equipment and cables connected to these connections.
