—————— HARDWARE DESCRIPTION ——————
2 10
GEI-100422
2.5 TECHNICAL SPECIFICATION
Storage temperature: -20°... +70°C (-68...+158°F)
Operating temperature: 0°... +55°C (32...+131°F)
These temperatures are adequate to those of the drive, to which the cards are
connected.
2.6 INTERFACE.
For the mechanical connection, according to the internal or external mounting,
please use the kit and the mounting instruction sheet supplied with the card.
For the electrical connection please use the 6KCV301PDP33-Drive link cable,
also supplied.
For the connection to the Bus please use a shielded twisted cable recommended
by Profibus specification.
The pinout of the Bus connectors are the following:
1
2
3
4
5
6
7
8
9
N.C.
+5V
100 ohm to 0V
N.C.
RX/TX-B
RX/TX-A
N.C.
N.C.
0V
(XS1 - XS2)
The connection among the single cards is implemented by a shielded cable as
shown in the following diagrams:
