Data Sheet KS-24194™ Power Wire
March 2010
Lineage Power 3
Features
■ Stranded, tin-coated, copper
conductors.
■ Primary wire insulation is
across-linked ethylene vinyl
acetate (EVA) copolymer
thermosetting material.
■ Available in a variety of colors.
Wire Classifications and
Ratings
■ UL Listed 600 V RHH; complies
with UL44 requirements for
building wire for cable tray (1/0
and larger) and raceway
applications in National
Electrical Code-defined dry
and damp locations.
■ UL Listed per UL1581 vertical
tray flame test (1/0 and larger)
UL Listed as RHH wire per
UL44 at 90 °C with or without
cotton braid.
■ Listed by UL as Telephone
Central Office Power Cable
rated 105 °C without cotton
braid and 90 °C with cotton
braid under Wires,
Miscellaneous Subject 805.
■ Listed by UL as Telephone
Central Office Power Cable
rated 60 °C for wet locations
under Wires, Miscellaneous
Subject 805.
■ UL Listed UL1685, FT4/IEEE
†
1202 Vertical Tray Fire
Propagation and Smoke
Release Test, which classifies
the wire as LS (Limited Smoke).
■ RHH is defined in the National
Electrical Code Section 310-13.
■ Meets Telcordia
GR-347-CORE, Issue 2.
■ Oxygen index exceeds 28%.
■ CSA
‡
Certified as Appliance
Wiring Materials (AWM) at 105
°C I B FT4, per CSA Standard
C22.2 No. 210.2 with/without
cotton braid cover.
■ UL recognized as AWM at 105
°C (without cotton-braid cover)
per UL Subject 758 (style
3578).
■ Directive 2002/95/EC
compliant (RoHS).
* To obtain a National Electrical Code
RHW rating, an RHH wire would also
require a 75°C wet rating.
† IEEE is a registered trademark of the
Institute of Electrical and Electronics
Engineers, Inc.
‡ CSA is a registered trademark of
Canadian Standards Association.
KS-24194 Power Wire Product Offering
KS-24194 Class I Stranded Conductor Specifications, List 2 and List 4
Product Stranding 1 Covering Gauges Colors
KS-24194 List 2 Class I
(Extra Flexible)
None 8 AWG - 750 kCMil Blue and Blue Tracer
2,3
, Black, Gray,
Red, and Red Tracer 2,3
KS-24194 List 3 Class B
(Non-Flexible)
Cotton Braid 14 AWG - 750 kCMil Black
4
, Blue, and Blue Tracer
2,5
,
Green, Gray, Ted, and Red Tracer
2,5
KS-24194 List 4 Class I Cotton Braid 1/0 AWG - 750 kCMil Gray, Red
6
, and Blue
6
1. Class I Stranding is per ASTM B-172; Class B Stranding is per ASTM B-8.
2. Tracer power wire has a special marking, similar to lines, running parallel on two sides of the wires.
3. Available in 4/0 AWG and 350 kCMil only.
4. Available in 10 AWG, 8 AWG, 6 AWG, and 2/0 AWG only.
5. Available in 4/0 AWG, 350 kCMil, 500 kCMil, and 750 kCMil.
6. Available in 750 kCMil.
Wire Size
AWG or
kCMil
Area
(CMil)
(Nom.)
Current
Capacity
(Amps) 1
Cond.
Dia.
(in)
Max dc
Resistance 2
Min Bend
Radius
(in) 3
No. of
Strands
Diameter (in)
List 2 List 4
Weight / 100 ft (lb)
List 2 List 4
Max Ship
Length
per Reel
8 16,510 55 0.156 0.6790 1-1/2 41 0.290 — 82 — 10,000
6 26,250 75 0.186 0.4360 1-5/8 65 0.320 — 116 — 6000
4 41,740 95 0.263 0.2740 2 105 0.405 — 188 — 4500
2 66,360 130 0.319 0.1720 2-3/8 161 0.465 — 279 — 3000
1/0 105,500 170 0.441 0.1090 3-1/8 266 0.625 0.665 452 479 2000
2/0 133,100 195 0.500 0.0868 3-3/8 342 0.685 0.725 563 593 1500
4/0 211,600 260 0.613 0.0546 4 532 0.800 0.840 835 870 1000
350 350,000 350 0.750 0.0334 4-7/8 855 0.965 1.020 1337 1378 700
500 500,000 430 0.941 0.0234 5-7/8 1221 1.170 1.225 1830 1906 500
750 750,000 535 1.100 0.0157 6-5/8 1850 1.345 1.400 2734 2792 350
1. Ampacities shown here are based on not more than three single, insulated conductors in a raceway with a 30 °C ambient temperature.
(Follow the National Electrical Code Article 310 Type RHH Correction Factors.)
2. In Ohms/1000 ft. at 20 °C.
3. Minimum bend radius is equal to five times the overall wire diameter.
