Data Sheet
12A Analog PicoDLynx TM : Non-Isolated DC-DC Power Modules
3Vdc –14.4Vdc input; 0.6Vdc to 5.5Vdc output; 12A Output Current
Contact Us
For more information, call us at
USA/Canada:
+1 888 546 3243 , or +1 972 244 9288
Asia-Pacific:
+86.021.54279977*808
Europe, Middle-East and Africa:
+49.89.74423-206
India:
+91.80.28411633
www.gecriticalpower.com
August 13, 2013 ©2013 General Electric Corporation. All rights reserved. Version 1.20
Ordering Information
Please contact your GE Sales Representative for pricing, availability and optional features.
Table 6. Device Codes
Device Code
Input
Voltage Range
Output
Voltage
Output
Current
On/Off
Logic
Sequencing Comcodes
PVX012A0X3-SRZ 3 – 14.4Vdc 0.6 – 5.5Vdc 12A Negative No CC109159686
PVX012A0X3-SRDZ 3 – 14.4Vdc 0.6 – 5.5Vdc 12A Negative No CC109168811
PVX012A0X43-SRDZ 3 – 14.4Vdc 0.6 – 5.5Vdc 12A Positive No CC109168828*
PVX012A0X43-SRZ 3 – 14.4Vdc 0.6 – 5.5Vdc 12A Positive No CC109159694*
-Z refers to RoHS compliant parts
*Please contact GE for more information
Table 7. Coding Scheme
Package
Identifier
Family Sequencing
Option
Output
current
Output
voltage
On/Off
logic
Remote
Sense Options
ROHS
Compliance
P V X 012A0 X 3 -SR -D Z
P=Pico
U=Micro
M=Mega
G=Giga
D=Dlynx
Digital
V =
DLynx
Analog.
T=with EZ
Sequence
X=without
sequencing
12A X =
programm
able output
4 =
positive
No entry
=
negative
3 =
Remote
Sense
S =
Surface
Mount
R =
Tape &
Reel
D = 105°C
operating
ambient,
40G
operating
shock as
per MIL Std
810F
Z = ROHS6
