GE
Data Sheet
QBVS050A0B Barracuda Series; DC-DC Converter Power Modules
52-60Vdc Input; 12.0Vdc, 50.0A, 600W Output
October 31, 2013
©2012 General Electric Company. All rights reserved.
Page 2
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are absolute stress ratings
only, functional operation of the device is not implied at these or any other conditions in excess of those given in the operations
sections of the Data Sheet. Exposure to absolute maximum ratings for extended periods can adversely affect device reliability.
Parameter
Device
Symbol
Min
Max
Unit
Input Voltage*
Continuous
V
IN
-0.3 60
V
dc
Non- operating continuous
V
IN
75
V
dc
Operating Ambient Temperature
All
T
A
-20 85
°C
(See Thermal Considerations section)
Storage Temperature
All
T
stg
-55 125
°C
I/O Isolation Voltage (100% factory Hi-Pot tested)
All
750 V
dc
* Input over voltage protection will shutdown the output voltage when the input voltage exceeds threshold level.
Electrical Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature conditions.
Parameter
Device
Symbol
Min
Typ
Max
Unit
Operating Input Voltage
V
IN
52 54
60
V
dc
Maximum Input Current
I
IN,max
- - 13
A
dc
(V
IN
=45V, I
O
=I
O, max
)
Input No Load Current
All I
IN,No load
175
mA
(V
IN
= V
IN, nom
, I
O
= 0, module enabled)
Input Stand-by Current
All I
IN,stand-by
20 mA
(V
IN
= V
IN, nom
, module disabled)
External Input Capacitance
All
120
600
-
μF
Inrush Transient
All
I
2
t - - 1
A
2
s
Input Reflected Ripple Current, peak-to-peak
(5Hz to 20MHz, 12μH source impedance; V
IN
= 48V, I
O
= I
Omax
;
see Figure 9)
All
- 40 -
mA
p-p
Input Terminal Ripple Current
(Measured at module input pin with maximum specified
input capacitance and ൏ 500uH inductance between
voltage source and input capacitance)
5Hz to 20MHz, V
IN
= 52V to 60V, I
O
= I
Omax
All
-
- 800
mA
rms
Input Ripple Rejection (120Hz)
All
-
25
-
dB
CAUTION: This power module is not internally fused. An input line fuse must always be used.
This power module can be used in a wide variety of applications, ranging from simple standalone operation to an integrated part
of sophisticated power architecture. To preserve maximum flexibility, internal fusing is not included, however, to achieve maximum
safety and system protection, always use an input line fuse. The safety agencies require a fast-acting fuse with a maximum rating
of 25A in the ungrounded input lead of the power supply (see Safety Considerations section). Based on the information provided in
this Data Sheet on inrush energy and maximum dc input current, the same type of fuse with a lower rating can be used. Refer to
the fuse manufacturer’s Data Sheet for further information.
