Load on phases screen 2
This screen displays for each phase:
• The Load active power (kW) (for RPA: total value of Parallel System).
• The Load apparent power (kVA) (for RPA: total value of Parallel System).
LOAD ON PHASES
L1= 17.95kW 22.44kVA
L2= 15.51kW 19.39kVA
L3= 16.17kW 20.22kVA
metering
alarms
parameters
+
–
ok
Miscellaneous screen
This screen displays:
• The temperature of the Inverter Bridge.
• The total operating time for the UPS (in hours).
• The total operating time for the Inverter (in hours).
MISCELLANEOUS
InvHeatsink = 45°C
UpsOperTime= 3125h
InvOperTime = 2135h
metering
alarms
parameters
+
–
ok
Utility Faults Statistics screen
This screen displays:
• The total number of minor Utility faults (Bypass Utility out of tolerance faults).
• The total number of major Utility faults (Rectifier Utility out of tolerance faults).
• The total number of detected output overloads.
UTILITY FAULTS STAT.
Minor =
43210
Major = 11267
Overloads= 654
metering
alarms
parameters
+
–
ok
UPS identification screen
This screen displays:
• The UPS family and the power range.
• The software version.
• The serial number.
UPS IDENTIFICATION
SG Series S0 80kVA
SW Version: x.xx
S/N: P0080-2006-0001
metering
alarms
parameters
+
–
ok
