Data Sheet
KHHD010A0A Hammerhead™ Series; DC-DC Converter Power Modules
18-75Vdc Input; 5.0Vdc, 8A/10A Output
February 24, 2014
©2012 General Electric Company. All rights reserved.
Page 4
General Specifications
Feature Specifications
Unless otherwise indicated, specifications apply at V
IN
= 48V
dc
, resistive load, and T
A
= 25°C conditions. See Feature Descriptions for
additional information.
Parameter
Device
Symbol
Min
Typ
Max
Unit
Remote On/Off Signal Interface
(V
IN
=V
IN, min
to V
IN, max
; open collector or equivalent,
Signal referenced to V
IN-
terminal)
Negative Logic: device code suffix “1”
Logic Low = module On, Logic High = module Off
Positive Logic: No device code suffix required
Logic Low = module Off, Logic High = module On
Logic Low - Remote On/Off Current (V
on/off
= -0.7V
dc
)
All
I
on/off
0.15
mA
Logic Low - On/Off Voltage
All
V
on/off
-0.7
0.8
V
dc
Logic High Voltage (I
on/off
= 0A
dc
)
All
V
on/off
2.4
7
V
dc
Logic High maximum allowable leakage current
All
I
on/off
25
μA
Turn-On Delay and Rise Times
(I
O
=80% of I
O, max
)
Case 1: Input power is applied for at least 1second, and then the
On/Off input is set from OFF to ON (T
delay
= on/off pin transition until
V
O
= 10% of V
O, set
)
All
T
delay
Case1
25
50
ms
Case 2: On/Off input is set to Module ON, and then input power is
applied
(T
delay
= V
IN
reaches V
IN, min
until V
O
= 10% of V
O,set
)
All
T
delay
Case2
35
50
ms
Output voltage Rise time (time for V
o
to rise from 10%
of V
o,set
to 90% of V
o, set
)
All
T
rise
5
10
ms
Output Voltage Overshoot
3
% V
O, set
(I
O
=80% of I
O, max
, V
IN
= 24 to 48V
dc
)
Output Overvoltage Protection
All
V
O, limit
6.0
7.0
V
dc
Input Undervoltage Lockout
Turn-on Threshold
All
V
uv/on
17
18
V
dc
Turn-off Threshold
All
V
uv/off
14
15
V
dc
Hysterisis
All
V
hyst
2.0
V
dc
Note: 1.The module requires a minimum of 680 μF external output capacitor to avoid exceeding the OVP maximum limits during startup into open
loop fault conditions.
Parameter
Min
Typ
Max
Unit
Calculated Reliability based upon Telcordia SR-332 Issue 2: Method
I
Case 3
(I
O
=80%I
O, max
, T
A
=40°C, airflow = 200 lfm, 90% confidence)
FIT
272.0
10
9
/Hours
MTBF
3,677,136
Hours
Weight
13 (0.46)
g (oz.)
