Functional connection diagram – GE Industrial Solutions AV-300i Quick Start User Manual
Page 7
7
Functional connection diagram
AC
Power
Supply
Cabinet
Mounting panel
ACDrive
AC
Line
Reactor
Ground
Bus
Motor
cable
terminals
AC Motor
Encoder cable
EMI filter
U1V1W1
U2V2W2PE2
PE1
AC Voltage
Contactor
AC fuses
Note:
PE1 is the drive safety ground. If PE2 is used to connect the motor ground, EMC filter ground must connected to PE1.
