———— KEYBOARD INTERFACE ———
7.0 KEYPAD INTERFACE
7.1 MAIN MENU STRUCTURE
This structure appears when the Enter key is pressed and “OPTION1” is
displayed; in this case, keypad control passes to the 6KCV300DVN card.
Option 1
OFFSET
POLL S->M
POLL M->S
DIGITAL INPUT
DIGITAL OUTPUT
PASSWORD
SBI INFO
DNM0010
Move between the Menus by pressing the Cursor-Up/Cursor-Down keys and
use the Enter key to enter the currently displayed Menu. Pressing the Cancel
key in any displayed menu causes the “OPTION1” Menu to appear and keypad
control returns to the Drive.
7.1.2 Control of warning and error messages
Warning and error messages can be displayed on the first and second rows of
the keypad’s display; a maximum of 16 characters can be displayed per line.
The Cancel key must be pressed in order to clear these messages, at this point
the system automatically returns to the immediately superior Menu level.
