—————— I/O Expansion card —————— 10
GEI-100427
4. JUMPERS
Following table describes the expansion board jumpers.
Name Description Default
Adaption to the unput signal of analog input O
ON 0…20mA / 4…20mA
OFF 0…10V / -10V…-10V
Adaption to the unput signal of analog input I
ON 0…20mA / 4…20mA
OFF 0…10V / -10V…-10V
expDA50
S3
OFF
OFF
JUMPERS ON BOARD
S2
I/O available depending on drive firmware version
Drive firmware 1.X from 2.X
Digital Inputs 4 12
Digital Outputs 6 8
Analog Inputs - 2
Analog Outputs 2 4
expDA75
5. LEDs
+5V ____________________ The led is lit when internal +5V power supply is
available from the Drive.
+15V ___________________ The led is lit when +15V power supply is provided by
the Drive
-15V ___________________ The led is lit when -15V power supply is provided by
the Drive
