9 —————— I/O Expansion card ——————
D14A4F
3.4 ANALOG OUTPUTS TERMINAL BOARD POINTS
Connector
Terminal 11 12 13 14 15
Function AQV0 GND AQV1 GND GND
expD40
ANALOG OUTPUTS
XAQV
3.5 ENCODER CONNECTION
The D14A4F expansion board adds a second digital encoder input via a 15
pins high density connector (VGA type). External power for the encoder (+5V
or +15V/24V) can be supplied thru terminals 93, 94, 95.
Connector
PIN 1 2 3 4 5 6 7 8
Signal
B-
(5V)
+24V
E
0+
(5V)
0-
(5V)
A+
(5V)
A-
(5V)
0VE
B+
(5V)
I/O I O I I I I O I
Connector
PIN 9 10 11 12 13 14 15
Signal +5VE
A+
(15V
up to
24V)
A-
(15V
up to
24V)
B+
(15V
up to
24V)
B-
(15V
up to
24V)
O+
(15V
up to
24V)
O-
(15V
up to
24V)
I/O O I I I I I I
expD50
ENCODER
XFI
XFI
WARNING!
5V and 15V-30V encoder signals cannot be intermixed in
the same connector.
Connector
Terminal 91 92 93 94 95
Signal C1+ C1- +5VE +24VE 0VE
expD60
ENCODER SUPPLY
XSI
