Infinity D Power System Installation Guide: -48V Plants H2007001
Issue 2.0, June 3, 2009 29
Step Action
Yes, insert each wire into the bottom of the
terminal block according to these diagrams:
R1 R2 R3 R4
L1 L2 L2 L3 L3 L1 L1 L2
200-240Vac Wiring Diagram for 3 Wire
+PE
R1 R2 R3 R4
L1 N L2 N L3 N L1 N
200-240Vac Wiring Diagram for 3 Wire +
neutral +PE [NON-US ONLY]
R1 R2 R3 R4
L1 L2 L1 L2 L1 L2 L1 L2
200-240Vac Wiring Diagram for 2 Wire +
PE
No, the shelf has a tiered terminal block that can
accept up to 8 AWG wires. Insert each feed wire into
the bottom of the terminal block according to these
diagrams:
R1
L1 R2
L2 R3
L3 R4
L1
R1
L2 R2
L3 R3
L1 R4
L2
200-240Vac Wiring Diagram for 3 Wire +PE
R1
L1 R2
L2 R3
L3 R4
L1
R1
N
R2
N
R3
N
R4
N
200-240Vac Wiring Diagram for 3 Wire + neutral
+PE [NON-US ONLY]
R1
L1 R2
L1 R3
L1 R4
L1
R1
L2 R2
L2 R3
L2 R4
L2
200-240Vac Wiring Diagram for 2 Wire + PE
10. Make sure all strands are captured in the appropriate wire clamp.
11.
Torque each wire clamp to 5-7 inch· lbs or 0.6-0.8 N·m.
12.
Secure conduit fitting.
13. Replace AC Termination door.
14. Tighten Screws to 5-7 inch·lbs or 0.6-0.8 N·m.
