GE Energy
Datasheet
2A DLynx TM : Non-Isolated DC-DC Power Modules
3Vdc –14Vdc input; 0.6Vdc to 5.5Vdc output; 2A Output Current
Contact Us
For more information, call us at
USA/Canada:
+1 888 546 3243 , or +1 972 244
9288
Asia-Pacific:
+86.021.54279977*808
Europe, Middle-East and Africa:
+49.89.878067-280
India:
+91.80.28411633
www.ge.com/powerelectronics
June 24, 2013 ©2012 General Electric Company. All rights reserved. Version 1.1
Ordering Information
Please contact your GE Energy Sales Representative for pricing, availability and optional features.
Table 6. Device Codes
Device Code
Input
Voltage Range
Output
Voltage
Output
Current
On/Off
Logic
Sequencing Comcodes
PNVX002A0X3-SRZ 3 – 14Vdc 0.6 – 5.5 Vdc 2A Negative No 150025978
PNVX002A0X3-SRDZ* 3 – 14Vdc 0.6 – 5.5 Vdc 2A Negative No TBD
-Z refers to RoHS compliant parts
* Check availability with GE Sales
Table 7. Coding Scheme
Package Family. Sequencing Output
current
Output
voltage
On/Off
logic
Remote
Sense
Options ROHS
Compliance
P NV X 002A0 X 4 3 -SR -D* Z
P : Pico
U : Micro
M : Mega
G : Giga
A : Pre-
4G
NV:
DLynx
analog
open
frame.
T: with EZ-
SEQUENCE
X: without EZ-
SEQUENCE
2.0A X =
programmable
output
4 =
positive
No entry =
negative 3 =
Remote
Sense
No entry
=
negative
S = Surface
Mount
R =
Tape&Reel
D = 105C
operating
ambient, 40G
operating
shock as per
MIL Std 810F
Z = ROHS6
