J85568E-1 Secondary DC Mini-Distribution Bay
Issue 6 January 2008 Installation 5 - 1
5 Installation
Safety
Read Section 4, Safety, carefully before installing the J85568E-1
Mini-Distribution Bay.
Tools and
Materials
Required
The following tools are required to install the Mini-Distribution
Bay:
• Equipment to handle shipping container, remove
Mini-Distribution Bay unit or framework, and erect unit in
final position (minimum lifting capacity of 220 pounds)
• Common electrician’s hand tools, including jeweler’s
screwdriver, electrical tape, wire cutters, and strippers for
8 AWG to 750 MCM
• Common mechanic’s hand tools, including flat blade
screwdriver, socket and torque wrenches for 1/4-inch and
3/8-inch bolts, and a crowbar for uncrating unit
• Proper crimping tools and dies for connectors. The
connectors specified are WP-91412, which may be installed
with compression tools made by Thomas & Betts using
color coded dies
• 3/4-inch drill to bore holes for floor anchors (List A only)
• Anchor bolts (List A only)
• 22-26 gauge stranded or solid wire for connecting alarms
• Terminal lugs for terminating distribution and load cables
• WP-92461 fuses and 1/2-ampere GMT alarm fuses
(comcode 401231501) or circuit breakers
