GE Industrial Solutions EntelliGuard G Racking Handle User Manual
Entelliguard, Circuit breaker accessories racking handle

Racking Handle
A Collapsible Racking Handle is provided to Rack
in/out the draw out breakers whenever needed.
Figure 1 Racking handle
Catalog No Description
GRHN
Racking handle
A storage provision is given in the draw out
cassette base plate. The racking handle can be
stored in the storage as shown in fig 2 when it is
straight
Figure 2 Racking Handle Storage tube
Application instructions:
The racking handle has two Configurations
1. Storage Configuration: This is the
configuration as the racking handles are
received. They will be Straight and shorter
in length (Collapsed) as show in Fig 3
Figure 3 Racking handle in Storage configuration
EntelliGuard
®
G
Circuit Breaker
Accessories
Racking Handle
WARNING: Before installing any accessories, turn the
breaker OFF, disconnect it from all voltage sources,
and discharge the closing spings.
AVERTISSEMENT: Avant d’installer tout accessoire,
mettre le disjoncteur en position OFF, le déconnecter
de toute tension d’alimentation , et décharger les
resorts d’armement
DEH-41392 Installation Instructions
Handel Installed in Storage
Storage Tube
