Outline drawings, Test, Modbus® concentrator – GE Industrial Solutions POWER LEADER Modbus Concentrator User Manual
Page 3: Power leader, Front view, Side view
Outline Drawings
TEST
TEST
0.250 dia.
5.904 in.
10.500 in.
g
POWER LEADER
Modbus® Concentrator
Segment Segment Segment Segment
A
B
C
D
+ - S + - S + - S + - S
Commnet Connecti ons
DI SPLAY
Sel ect
s
t
Enter
RS- 485 In/Out
0.213 dia.
3.350 in.
3.025 in.
2.375 in.
STATUS
LEDs
Contr ol Power
85Vac- 265Vac
100Vdc- 250Vdc
+ - S + - S + - S + - S
Segment Segment Segment Segment
E
F
G
H
Commnet Connecti ons
0.64 in.
6.000 in.
9.312 in.
3.466 in.
2.520 in.
2.312 in.
2.312 in.
0.250 in.
10.000 in.
0. 594 in.
3.466 in.
2.520 in.
Gr oundi ng
Scr ew
+ - S
+ - S
Front View
Mount ing Sur face
Gr ounding
Scr ew
6. 000 in.
3.400 in.
2.137 in.
0. 640 in.
Side View
