Standard Features
• One-piece steel case construction
– Simple installation (no cutouts)
• Ease of operation
– Four-character alphanumeric high-contrast LED
display
– Simple four-button keypad
– All setup done via faceplate keypad and display; no
confusing DIP switches
– Quick automatic setup capability
• Communications
– Communicates on POWER LEADER commnet
communications protocol
– Communicates on Modbus RTU communications
protocol
– Each Modbus Concentrator supports up to 32
commnet devices (maximum 215 Commnet
devices per RS485 network possible with multiple
Concentrators)
Product Specifications
Catalog Number
Description Catalog Number
POWER LEADER
Modbus Concentrator
PLZOOMG01
Communications
• POWER LEADER Eight individual segments
commnet supporting up to
four devices per segment
• Modbus RTU One RS485 input port,
One RS485 output port
(1200 baud, 2400 baud,
4800 baud, 9600 baud,
and 19.2 Kbaud)
Power Requirements
• Control power 85 Vac – 265 Vac
100 Vdc – 250 Vdc
Standards
• UL listed 508 & 840
• CSA certified C22.2 No. 14
Environment
• Operating temperature range –0° to +70° C
• Storage temperature range –20° to +80° C
• Relative humidity 5% to 95%
noncondensing
• Vibration response and IEC 255-21-1
endurance Severity Class 1
• Fast transient surge ANSI C37.90.1
• Radiated EMI withstand ANSI C37.90.2
capability
• Electrostatic discharge IEC 801-2
Severity Class 4
Supported POWER LEADER commnet Devices
Meters
• POWER LEADER Meter
• POWER LEADER Electronic Power Meter
Protection and Control Devices
• Spectra RMS™ Electronic Control Module
• POWER LEADER MDP200 Overcurrent Relay
Other Devices
• POWER LEADER Repeater
• POWER LEADER Junction Box
Trip Units
• MicroVersaTrip for Spectra Molded Case circuit
breakers (RMS6)
• MicroVersaTrip for Power Break and Type AKR
circuit breakers (RMS9C)
• MicroVersaTrip for Power Break II circuit breakers
(RMS9D)
