Data Sheet
12V PicoTLynx TM 6A: Non-Isolated DC-DC Power Modules
4.5Vdc –14Vdc input; 0.59Vdc to 5.5Vdc output; 6A Output Current
Contact Us
For more information, call us at
USA/Canada:
+1 888 546 3243 , or +1 972 244 9288
Asia-Pacific:
+86.021.54279977*808
Europe, Middle-East and Africa:
+49.89.74423-206
India:
+91.80.28411633
www.ge.com/powerelectronics
May 2, 2013 ©2013 General Electric Company. All rights reserved. Version 1.15
Ordering Information
Please contact your GE Sales Representative for pricing, availability and optional features.
Table 6. Device Codes
Device Code
Input
Voltage Range
Output
Voltage
Output
Current
On/Off
Logic
Sequencing Comcodes
APTS006A0X-SRZ 4.5 – 14Vdc 0.59 – 5.5Vdc 6A Negative Yes CC109126026
APTS006A0X4-SRZ 4.5 – 14Vdc 0.59 – 5.5Vdc 6A Positive Yes CC109126034
APXS006A0X-SRZ 4.5 – 14Vdc 0.59 – 5.5Vdc 6A Negative No CC109126001
APXS006A0X4-SRZ 4.5 – 14Vdc 0.59 – 5.5Vdc 6A Positive No CC109126018
APXS006A0X-25SRZ* 4.5 – 14Vdc 0.59 – 5.5Vdc 6A Negative No CC109142205
APXS006A0X-SRDZ 4.5 – 14Vdc 0.59 – 5.5Vdc 6A Negative No CC109150240
APTS006A0X-62SRZ* 4.5 – 14Vdc 0.59 – 5.5Vdc 6A Negative Yes CC109172755
* Special codes, consult factory before ordering
Table 7. Coding Scheme
TLynx
family
Sequencing
feature.
Input
voltage
range
Output
current
Output voltage On/Off
logic
Options ROHS
Compliance
AP T S 006A0 X 4 -SR -D Z
T = with Seq.
X = w/o Seq.
S = 4.5 -
14V
6.0A X =
programmable
output
4 = positive
No entry =
negative
S = Surface
Mount
R = Tape&Reel
D = 105C
operating
ambient, 40G
operating shock
as per MIL Std
810F
Z = ROHS6
