Instructions
SK (Max Amps)
Catalog Numbers Trip Amps 800 1000 1200
GTP0300U0408 300 x
GTP0350U0408 350 x
GTP0400U0410 400 x
GTP0450U0612 450 x x x
GTP0500U0613 500 x x x
GTP0600U0616 600 x x x
GTP0700U0816 700 x x x
GTP0750U0820 750 x x x
GTP0800U0820 800 x x x
GTP0900U1020 900 x x
GTP1000U1025 1000 x x
GTP1100U1225 1100 x
GTP1200U1232 1200 x
Table 1. Catalog numbering system for Spectra® RMS SK Frame breakers with microEntelliGuard™ trip units
SK PC 36 12 L4 R 6
Code Description Function
SK SK1200 Frame Designation
HC
LC/TC
1
PC/SC 1
HH
LL/TT
1
PP/SS 1
50kA at 480Vac
65kA at 480Vac Standard UL Rating
100kA at 480 Vac
50kA at 480Vac
65kA at 480Vac 100% Continuous UL Rating
100kA at 480 Vac
Interruption Rating
3, 4 or 6 3 Poles, 480Vac or 600Vac Poles, Max UL Voltage
08 800 Amps
10 1000 Amps SK Frame
12 1200 Amps
L3 LSI
L = Long Time
S = Short Time
L4 LSIG
I = Instantaneous
L5 LSIA
G = Ground Fault
A = Ground Fault Alarm
L7 LSI-CP
CP = Control Power
X None
K Neutral Protection
Z ZSI (ST/GF)
T ZSI (ST/GF/INST)
R RELT
L ZSI (ST/GF) + RELT
M ZSI (ST/GF) + Neutral Protection
N ZSI (ST/GF) + RELT + Neutral Protection
V RELT + Neutral Protection
P ZSI (ST/GF/INST) + RELT
S ZSI (ST/GF/INST) + Neutral Protection
W ZSI (ST/GF/INST) + RELT + Neutral Protection
X Metering (Basic)
2 Metering (Basic) + Modbus
6 Metering (Adv) + Modbus + Waveform Capture
8 Metering (Adv) + Modbus + Waveform Capture + Protective Relays
Max Amps
Standard Protection
Functions
Advanced Protection
Functions
Advanced Features &
Communications
Example – a breaker with catalog number
SKPC3612L4R6 has the following features:
1 SK1200 frame (SK)
2 100 kA at 480 Vac Standard UL rating (PC)
3 3 pole, 600 Vac maximum (36)
4 1200 A sensors (12)
5 Long-time, Short-time, Instantaneous and Ground
Fault functions (L4)
6 RELT – Reduced Energy Let-Through (R)
7 Advance Metering, Modbus Communications, and
Waveform Capture (6)
2. Following the instructions supplied with the rating
plug, install the plug into the breaker body. Available
rating plugs, with their catalog numbers, are listed in
Table 2.
1. SKT and SKS catalog codes are optimized for selectivity and will carry a
480Vac maximum voltage rating.
Table 2. SK Frame Rating Plugs
