Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 6. Device Codes
Device Code
Input
Voltage
Range
Output
Voltage
Output
Current
On/Off
Logic
Sequencing
Comcodes
APTS050A0X3-SRPHZ
4.5 – 14Vdc
0.7 – 2.0Vdc 50A Negative Yes
CC109155314
APTS050A0X3-SRPHDZ
4.5 – 14Vdc
0.7 – 2.0Vdc
50A
Negative
Yes
CC109170585
Table 7. Coding Scheme
TLynx
family
Sequencing
feature.
Input
voltage
range
Output
current
Output
voltage
On/Off
logic
Remote
Sense
Options
ROHS
Compliance
AP T S
050A0
X
3
-SRPHD Z
T = with Seq.
S = 4.5 -
14V
50A
X =
programm
able output
No entry
=
negative
4 =
positive
3 =
Remote
Sense
S = Surface
Mount
R = Tape&Reel
P = Paralleling
H=2 ground
pins
D = 105°C
operating
ambient, 40G
operating
shock as per
MIL Std 810F
Z = ROHS6
