GE
Data Sheet
9-36V ProLynx
TM
3A: Non-Isolated DC-DC Power Modules
9Vdc –36Vdc input; 3Vdc to 18Vdc output; 3A to 1.5A Scaled output current
9Vdc –24Vdc input; -3.3Vdc to -12Vdc output; 3A to 0.7A Scaled output current
Contact Us
For more information, call us at
USA/Canada:
+1 888 546 3243
, or +1 972 244
9288
Asia-Pacific:
+86.021.54279977*808
Europe, Middle-East and Africa:
+49.89.878067-280
India:
+91.80.28411633
www.ge.com/powerelectronics
July 23, 2013
©2013 General Electric Company. All rights reserved.
Version 1.8
Ordering Information
Please contact your GE Sales Representative for pricing, availability and optional features.
Table 7. Device Codes
Device Code
Input
Voltage Range
Output
Voltage
Output
Current
On/Off
Logic
Connecto
r
Type
Comcodes
APXW003A0X3-SRZ
9 – 36Vdc or
9 – 24Vdc in
negative output
application
3 – 18Vdc or
-3.3 to -12Vdc in
negative output
application
3A – 1.5A or
3A – 0.7A in
negative
output
application
Negative SMT CC109161238
APXW003A0X43-SRZ Positive
SMT
CC109161246
-Z refers to RoHS compliant parts
Table 8. Coding Scheme
TLynx
family
Sequencing
feature.
Input
voltage
range
Output
current
Output voltage
On/Off logic
Options
ROHS
Compliance
AP X W
003 X
4
-SR
Z
X = w/o Seq. W = 9 - 36V
3A
X = programmable
output
4 = positive
No entry =
negative
S = Surface Mount
R = Tape&Reel
Z = ROHS6
