Installation and Maintenance Tools
8.1
Installation Tools
TTyyppee
C
Chhaarraacctteerriissttiiccss
Slotted Screwdriver
3/16” or ¼”
Socket/Ratchet
Socket sizes: M5
Electric Hammer Drill
Wire stripper, hammer, wrench and anchor bolts*
TTaabbllee 22
* Use 1/2” x 6” Hexagonal Sleeve Anchor bolts
8.2
Maintenance tools
TTyyppee
C
Chhaarraacctteerriissttiiccss
Slotted Screwdriver
3/16” or ¼”
Drill Bit
T-15
Socket/Ratchet
Socket sizes: M3, M5
TTaabbllee 33
9
Field cable size
PPoow
weerr w
wiirreess::
Cu: 8 AWG
,
minimum 75 ° C wires
G
Grroouunndd w
wiirreess
Cu: 8 AWG, minimum 75 ° C wires
C
Coom
mm
muunniiccaattiioonn w
wiirreess
CAT5 Ethernet cable
W
WAARRN
NIIN
NG
G:: Make sure power to
the EVSE is disconnected before
performing any task
