GE Industrial Solutions Spectra RMS Cable Operators - Manual (Page 6)

g
GE Industrial Systems
General Electric Company
41 Woodford Ave., Plainville, CT 06062
DEH-40467 R02 0198© 2001 General Electric Company
These instructions do not cover all details or variations in equipment nor do they provide for every possible
contingency that may be met in connection with installation, operation, or maintenance. Should further
information be desired or should particular problems arise that are not covered sufficiently for the purchaser’s pur-
poses, the matter should be referred to the GE Company.
Table 5. Hardware Details
6
CATALOGUE
NO.
S.NO. PART NO. NAME OF THE PART QTY/ASSY. Breaker
1 10087146P1 Steel pipe 2
2 N66P19056B #12-24 x 3 ½” Steel Screws 2
3 N210P19B6 # 12-24 Nut 3
4 N402P10B6 Washer, Steel Plate 6
5 N402P40B6 Washer 2
6 10086816P1 Compression Spring 1
7 10087374P1 #10-32 Hex Nut (Cable) 4
SRCM1EF
8 N37P19012B6 #12-24 x 3/4” Steel Screw 1
SE150/ SF250
1 10087146P2 Steel pipe 2
2 N66P19056B #12-24 x 3 ½” Steel Screws 2
3 N210P19B6 #12-24 Nut 3
4 N402P10B6 Washer, Steel Plate 6
5 N402P40B6 Washer 2
6 10086816P1 Compression Spring 1
7 10087374P1 #10-32 Hex Nut (Cable) 4
SRCM1G
8 N37P19012B6 #12-24 x 3/4” Steel Screw 1
SG600
1 10087146P2 Steel pipe 2
2 N66P19056B 12-24 x 3 ½” Steel Screws 2
3 N210P19B6 #12-24 Nut 3
4 N402P10B6 Washer, Steel Plate 6
5 N402P41B6 Washer 2
6 10086816P2 Compression Spring 1
7 10087374P2 Hex Thin Jam Nut (Cable) 4
SRCM1K
8 N37P19012B6 #12-24 x 3/4” Steel Screw 1
SK1200
