CAR2548TN series rectifier
Input: 90Vac to 264Vac; Output: -54 Vdc @ 2500W; 3.3Vdc or 5 Vdc @ 1A
April 23, 2013 ©2012 General Electric Company. All rights reserved. Page 3
-54V
dc
MAIN OUTPUT (continued)
Parameter Device Symbol Min Typ Max Unit
Remote ON/OFF delay time All 40 ms
Turn-ON rise time (10 – 90% of V
out
) All 60 ms
Transient response 50% step [10%-60%, 50% - 100%]
(dI/dt – 1A/µs, recovery 300µs)
All
V
out
-1350 +1350 mV
dc
Programmable range (hardware & software) All -45 -57 V
dc
Overvoltage protection, latched
(recovery by cycling OFF/ON via hardware or software) All
-58 -59 -60 V
dc
Output current V
out
= -54V
dc
All I
out
0 46.3 A
dc
Power limit 2500W V
out
-42 -58 V
dc
Current limit, Hiccup (programmable level) All I
out 106 126 % of FL
Active current share All I
out -5 +5 % of FL
AUXILIARY OUTPUT
Parameter Device Symbol Min Typ Max Unit
Set point All V
out
3.3 / 5.0 V
dc
Overall regulation (load, temperature, aging) All V
out
-5 +5 %
Ripple and noise All 50 mVp-p
Output current All I
out
0 1 A
dc
Overload protection -
Overvoltage protection
Isolation Output/GND All 100 V
dc
Environmental, Reliability
Parameter Min Typ Max Units Notes
Ambient Temperature
Operating
Altitude Operating
Power Derating
-10 3 50
2250
2.5
°C
m
%/°C
Air inlet from sea level to 5,000 feet.
7400 ft
51°C to 70C
Storage
Altitude non-operating -40 85
8200
°C
m
30,000 ft
Humidity Operating
Storage 30
10 95
95
%
Relative humidity, non-condensing
Shock and Vibration acceleration 6 Grms NEBS GR-63-CORE, Level 3 20 -2000Hz, minimum 30 minutes
Earthquake Rating 4 Zone
NEBS GR-63-CORE, all floors, Seismic Zone 4 Designed and tested
to meet NEBS specifications.
MTBF
100,000
200,000
Hrs
Full load, 50C ambient, per Bellcore RPP
Demonstrated
3 Designed to start at an ambient down to -40°C; meet spec after  30 min warm up period, may not meet operational limits below -10°C.
