GE Energy
Data Sheet
6A Austin MicroLynx TM II: Non-Isolated DC-DC Power Modules
8.3Vdc –14Vdc input; 0.75Vdc to 5.5Vdc output; 6A Output Current
October 16, 2012 ©2012 General Electric Company. All rights reserved. Page 11
Design Considerations (continued)
Output Filtering
The Austin MicroLynx TM II 12V module is designed for low
output ripple voltage and will meet the maximum output ripple
specification with 1 µF ceramic and 10 µF polymer capacitors
at the output of the module. However, additional output
filtering may be required by the system designer for a number
of reasons. First, there may be a need to further reduce the
output ripple and noise of the module. Second, the dynamic
response characteristics may need to be customized to a
particular load step change.
To reduce the output ripple and improve the dynamic response
to a step load change, additional capacitance at the output
can be used. Low ESR polymer and ceramic capacitors are
recommended to improve the dynamic response of the
module. For stable operation of the module, limit the
capacitance to less than the maximum output capacitance as
specified in the electrical specification table.
Safety Considerations
For safety agency approval the power module must be
installed in compliance with the spacing and separation
requirements of the end-use safety agency standards, i.e., UL
60950-1, CSA C22.2 No. 60950-1-03, and VDE 0850:2001-12
(EN60950-1) Licensed.
For the converter output to be considered meeting the
requirements of safety extra-low voltage (SELV), the input must
meet SELV requirements. The power module has extra-low
voltage (ELV) outputs when all inputs are ELV.
The input to these units is to be provided with a fast-acting
fuse with a maximum rating of 6A in the positive input lead
.
