1.2.5 Abbreviations and Standards
Abbreviations: Terms: SI-units: I-P units:
a Acceleration m/s 2 ft/s 2
AWG American wire gauge
Auto Tune Automatic Motor Tuning
°C Celsius
I Current A Amp
I
LIM
Current limit
DCT Drive Control Tool
Joule Energy J = N ∙m ft-lb, Btu
°F Fahrenheit
f Frequency Hz Hz
kHz Kilohertz kHz kHz
mA Milliampere
ms Millisecond
min Minute
M-TYPE Motor Type Dependent
Nm Newton Metres in-lbs
I
M,N
Nominal motor current
f
M,N
Nominal motor frequency
P
M,N
Nominal motor power
U M,N Nominal motor voltage
par. Parameter
PELV Protective Extra Low Voltage
Watt Power W Btu/hr, hp
Pascal Pressure Pa = N/m² psi, psf, ft of water
I
INV
Rated Drive Output Current
RPM Revolutions Per Minute
SR Size Related
T Temperature C F
t Time s s,hr
T LIM Torque limit
U Voltage V V
Table 1.2: Abbreviation and Standards table .
1.2.6 HP/kW Conversion
A conversion index for determining kW and HP ratings is shown below.
kW HP kW HP
0.25 0.33 45 60
0.37 0.5 55 75
0.55 0.75 75 100
0.75 1.0 90 125
1.1 1.5 110 150
1.5 2.0 132 175
2.2 3.0 160 200
3.0 - 200 300
4.0 5.0 250 -
5.5 7.5 300 -
7.5 10 315 350
11 15 355 450
15 20 400 500
18.5 25 450 600
22 30
30 40
37 50
