No.
Description
Warning
Alarm/Trip
Alarm/Trip Lock
Parameter Reference
1
10 Volts low
X
2
Live zero error
(X)
(X)
par. AN-01 Live Zero Time-
out Function
3
No motor
(X)
par. H-80 Function at Stop
4
Mains phase loss
(X)
(X)
(X)
par. SP-12 Function at Line
Imbalance
5
DC link voltage high
X
6
DC link voltage low
X
7
DC over voltage
X
X
8
DC under voltage
X
X
9
Inverter overloaded
X
X
10
Motor Electronic Overload over temperature
(X)
(X)
par. F-10 Electronic Over-
load
11
Motor thermistor over temperature
(X)
(X)
par. F-10 Electronic Over-
load
12
Torque limit
X
X
13
Over Current
X
X
X
14
Earth fault
X
X
X
15
Incomp. HW
X
X
16
Short Circuit
X
X
17
Control word timeout
(X)
(X)
par. O-04 Control Word
Timeout Function
23
Internal fans
24
External fans
25
Brake resistor short-circuited
X
26
Brake resistor power limit
(X)
(X)
par. B-13 Braking Thermal
Overload
27
Brake chopper short-circuited
X
X
28
Brake check
(X)
(X)
par. B-15 Brake Check
29
Power board over temp
X
X
X
30
Motor phase U missing
(X)
(X)
(X)
par. H-78 Missing Motor
Phase Function
31
Motor phase V missing
(X)
(X)
(X)
par. H-78 Missing Motor
Phase Function
32
Motor phase W missing
(X)
(X)
(X)
par. H-78 Missing Motor
Phase Function
33
Inrush fault
X
X
34
Network communication fault
X
X
36
Mains failure
38
Internal fault
X
X
40
Overload T27
41
Overload T29
42
Overload X30/6-7
47
24 V supply low
X
X
X
48
1.8 V supply low
X
X
49
Speed limit
50
Auto Tune calibration failed
X
51
Auto Tune check U
nom
and I
nom
X
52
Auto Tune low I
nom
X
53
Auto Tune motor too big
X
54
Auto Tune motor too small
X
55
Auto Tune parameter out of range
X
56
Auto Tune interrupted by user
X
57
Auto Tune timeout
X
58
Auto Tune internal fault
X
X
59
Current limit
X
60
External interlock
62
Output Frequency at Maximum Limit
X
64
Voltage Limit
X
65
Control Board Over-temperature
X
X
X
66
Heat sink Temperature Low
X
67
Option Configuration has Changed
X
70
Illegal Drive configuration
80
Drive Initialised to Default Value
X
92
No-Flow
X
X
Par. AP-2#
93
Dry Pump
X
X
Par. AP-2#
94
End of Curve
X
X
Par. AP-5#
95
Broken Belt
X
X
Par. AP-6#
96
Start Delayed
X
Par. AP-7#
97
Stop Delayed
X
Par. AP-7#
98
Clock Fault
X
K-7#
Table 7.1: Alarm/Warning code list
