6

28,5 mm

53 mm

t

c

22 mm

1,5 mm

5 mm

C1

PRI

C5

L1

C2

R1

HK2

R12

L2

D7

C4

D2

D3

C5

L3

L4

SEC

FUSI

0,27R

53 mm

t

c

22

94

33

88

83

2

Fig. 4

HALOTRONIC

®

for installation in luminaires

Design

Square Board

Reference

HT 50/230-240/2 SB

HTN 75/230-240 S

Nominal mains voltage

230 V - 240 V

230 V - 240 V

Voltage range

207 - 254 V

207 - 254 V

Mains frequency

50/60 Hz

50/60 Hz

Operating frequency

45 kHz

ca. 48 kHz

Mains current

0.22 A

0,32 A

Power factor

0.95

0,95

Max. lamp wattage

50 W

75 W

Power loss

2.5 W

max. 4 W

Partial load range

20 - 50 W

20 - 75 W

Secondary voltage

.5 V (50 W)

.5 V (75 W)

.4 V (20 W)

.7 V (20 W)

Temperature range

0 °C to + 70 °C

0 °C to + 50 °C

tc

00 °C

85 °C

Terminal pairs
primary/secondary

-

/

Dimming

Trailing-edge phase dimmer

Trailing-edge phase dimmer

Short circuit protection

Electronically reversible

Electronically reversible

Overload protection

Electronically reversible

Electronically reversible

Over-temp. protection

Electronically reversible

Electronically reversible

Approval marks

Radio interf. suppressior

EN 5505

EN 5505

Harmonics

EN 6000-3-2

EN 6000-3-2

Immunity

EN 6547

EN 6547

Length l

53 mm

94 mm

Width b

53 mm

33 mm

Height h

28.5 mm

22 mm

Weight

52 g

70 g

EAN

4050300

861678

400832

909329

Fig.

2
