Varistor Products
MLA Automotive Varistor Series
Surface Mount Multilayer Varistors (MLVs) > MLA Automotive Series
Specifications are subject to change without notice.
Please refer to www.littelfuse.com/series/ML.html or MLA.html for current information.
Device Ratings and Specifications
Part Number
Maximum Ratings (125º C)
Specifications (25ºC)
Maximum
Continuous
Working
Voltage
Jump
Start
Voltage
(5 min)
Load
dump
Energy
Maximum
Non-repetitive
Surge Current
(8/20
µs)
Maximum
Non-repetitive
Surge Energy
(10/1000
µs)
Maximum
Clamping
Voltage
at 1A (or
as Noted)
(8/20
µs)
Nominal
Voltage at
1mA DC Test
Current
Typical
Capacitance
at f = 1MHz
V
M(DC)
V
M(AC)
V
JUMP
W
LD
I
TM
W
TM
V
C
V
N(DC)
Min
V
N(DC)
Max
C
(V)
(V)
(V)
(J)
(A)
(J)
(V)
(V)
(V)
(pF)
V3.5MLA0603NHAUTO
3.5
2.5
--
--
30
0.100
13.0
3.7
7.0
1270
V3.5MLA0805NHAUTO
3.5
2.5
--
--
120
0.300
13.0
3.7
7.0
2530
V3.5MLA0805LNHAUTO
3.5
2.5
--
--
40
0.100
13.0
3.7
7.0
1380
V3.5MLA1206NHAUTO
3.5
2.5
--
--
100
0.300
13.0
3.7
7.0
6000
V5.5MLA0603NHAUTO
5.5
4.0
--
--
30
0.100
17.5
7.1
9.3
500
V5.5MLA0805NHAUTO
5.5
4.0
--
--
120
0.300
17.5
7.1
9.3
1840
V5.5MLA0805LNHAUTO
5.5
4.0
--
--
40
0.100
17.5
7.1
9.3
400
V5.5MLA1206NHAUTO
5.5
4.0
--
--
150
0.400
17.5
7.1
9.3
3500
V9MLA0603NHAUTO
9.0
6.5
--
--
30
0.100
25.5
11.0
16.0
490
V9MLA0805LNHAUTO
9.0
6.5
--
--
40
0.100
25.5
11.0
16.0
520
V12MLA0805LNHAUTO
12.0
9.0
--
--
40
0.100
29.0
14.0
18.5
410
V14MLA0603NHAUTO
14.0
10.0
--
--
30
0.100
34.5
15.9
21.5
180
V14MLA0805NHAUTO
14.0
10.0
--
--
120
0.300
32.0
15.9
20.3
560
V14MLA0805LNHAUTO
14.0
10.0
--
--
40
0.100
32.0
15.9
20.3
320
V14MLA1206NHAUTO
14.0
10.0
--
--
150
0.400
32.0
15.9
20.3
1400
V18MLA0603NHAUTO
18.0
14.0
24.5
0.3
30
0.100
50.0
22.0
28.0
120
V18MLA0805NHAUTO
18.0
14.0
24.5
1
120
0.300
44.0
22.0
28.0
520
V18MLA0805LNHAUTO
18.0
14.0
24.5
0.7
40
0.100
44.0
22.0
28.0
290
V18MLA1206NHAUTO
18.0
14.0
24.5
1.5
150
0.400
44.0
22.0
28.0
1270
V18MLA1210NHAUTO
18.0
14.0
24.5
3
500
2.500
44.0 at 2.5
22.0
28.0
1440
V26MLA0603NHAUTO
26.0
20.0
27.5
0.4
30
0.100
60.0
31.0
38.0
110
V26MLA0805NHAUTO
26.0
20.0
27.5
1
100
0.300
60.0
29.5
38.5
220
V26MLA0805LNHAUTO
26.0
20.0
27.5
0.7
40
0.100
60.0
29.5
38.5
140
V26MLA1206NHAUTO
26.0
20.0
27.5
1.5
150
0.600
60.0
29.5
38.5
600
V26MLA1210NHAUTO
26.0
20.0
27.5
3
300
1.200
60.0 at 2.5
29.5
38.5
1040
V30MLA0603NHAUTO
30.0
25.0
29
0.4
30
0.100
74.0
37.0
46.0
90
V30MLA0805LNHAUTO
30.0
25.0
29
0.7
30
0.100
72.0
37.0
46.0
90
V30MLA1210NHAUTO
30.0
25.0
29
3
280
1.200
68.0 at 2.5
35.0
43.0
1820
V30MLA1210LNHAUTO
30.0
25.0
29
3
220
0.900
68.0 at 2.5
35.0
43.0
1760
V33MLA1206NHAUTO
33.0
26.0
36
1.5
180
0.800
75.0
38.0
49.0
500
V42MLA1206NHAUTO
42.0
30.0
48
1.5
180
0.800
92.0
46.0
60.0
425
V48MLA1210NHAUTO
48.0
40.0
48
3
250
1.200
105.0 at 2.5
54.5
66.5
520
V48MLA1210LNHAUTO
48.0
40.0
--
--
220
0.900
105.0 at 2.5
54.5
66.5
500
NOTES:
1 'L' suffix is a low capacitance and energy version; Contact your Littelfuse sales representative for custom capacitance requirements
2 Typical leakage at 25ºC<25µA, maximum leakage 100µA at V
M(DC)
3 Average power dissipation of transients for 0603, 0805, 1206 and 1210 sizes not to exceed 0.05W, 0.1W, 0.1W and 0.15W respectively
