A.2 - Specifications
Analog Inputs:
Number of Inputs:
(2) Switchable line or mic inputs
Connectors:
Female XLR line inputs and Euroblock
Type:
Electronically balanced/RF filtered
Impedance:
> 50kΩ
Max input line level:
+20dBu
CMRR:
> 40dB, typically >55db @ 1kHz
Mic Pre gain:
30 to 60dB
Mic EIN:
< 118dB, 22Hz-22kHz, 150Ω
Mic Phantom Power:
15V
Analog Outputs:
Number of Outputs:
(2)
Connectors:
Male XLR and Euroblock
Type:
Electronically balanced, RF filtered
Impedance:
120 Ω balanced, 60Ω unbalanced
Max Output Level:
+20dBu
A/D Performance:
Type:
dbx Type IV™ conversion system
Dynamic Range line:
>113 dB A-weighted, >110 dB unweighted
Type IV dynamic range:
>119 dB, A-weighted, 22kHz BW
>117 dB, unweighted, 22kHz BW
Sample Rate:
48kHz
D/A Performance:
Dynamic Range:
112 dB A-weighted, 109dB unweighted
System Performance:
Dynamic Range:
>110 dB A-weighted, >107dB unweighted,
THD+N:
0.003% typical at +4dBu, 1kHz, 0dB gain
Frequency Response:
20Hz – 20kHz, +/- 0.5dB
Interchannel Crosstalk:
>110dB, 120dB typical
Crosstalk input to output:
>80dB
Propagation Delay:
0.6 msec
Operating voltage:
100 VAC, 50/60Hz, 120 VAC, 60Hz, 230VAC 50/60Hz
Power Requirements:
12 Watts
Physical:
Weight:
5.5 lbs.(2.5 kg) Shipping weight 7 lbs. (3.18 kg)
Dimensions:
1.75” H x 5.75” D x 19” W
