The Utility section of the DriveRack 220i gives you the ability to perform several key
operational functions including: custom Program List creation, Zone Controller set-
tings, and front panel lockout mode selection. Use this section of the manual to make
yourself familiar with all aspects of the Utility menu of the DriveRack system.
4.1 - Program List/Program Change
The 220i allows you to set the unit to either scroll through programs in a sequential manner, or create
custom program lists from within the Utility menu. This list makes it convenient for restricting access to
a small list of programs. The procedure for setting up the program list is as follows.
Open the Utility menu by clicking on Edit on the Menu Bar, and selecting Utilities.
To create a custom Program list first, select the desired list size by using the up and down arrows to the
right of the Program List Size indicator.
Select the programs in the list by clicking on one of the programs then use the up and down arrows at
the bottom of the window to select which program from the user program table you want.
4.2 - ZC Setup
This feature gives you the ability to create a custom interface for the end user and program that interface
for either program selection or output level and mute.
The Zone Controllers offer additional utility to the DriveRack ® 220i. They allow real-time adjustment of
output levels, mutes and program changes from simple wall panel interfaces. On the 220i, a maximum
number of six Zone Controllers may be used and they may be nested, in other words, one controller
may be used for a single zone and then another controller may be used for the entire venue or system.
With a maximum distance of up to 1000 ft. on CAT5 cable with RJ-45 connectors, the Zone Controllers
offer an easy to program and use remote control surface.
