RMLH / RMLHC INSTRUCTION
MANUAL/EN/07.20.10
6/9
This document and the information contained herein, is the exclusive property of R&M Materials Handling, Inc., and represents a non-public, confidential and proprietary trade secret
that may not be reproduced, disclosed to third parties, altered or otherwise employed in any manner whatsoever without the express written consent of R&M Materials Handling, Inc.
Copyright © (2010) R&M Materials Handling, Inc. All rights reserved.
3 RMLH PUSH TROLLEY & RMLHC HAND-GEARED TROLLEY
3.1 Description of the RMLH Push Trolley and the RMLHC Hand-
geared Trolley
RMLH and RMLHC trolley models have a single beam flange width to cover a wide range of beam flange
widths.
The trolley wheels are single flange and crown tread type suitable for Wide Flange beams or tapered flange
beams.
Wheel bearings are permanently lubricated and do not require greasing.
Trolleys have safety drop lugs and rubber bumpers are standard.
Capacity range of the RMLH Push trolley models is ½ ton [500 kg] to 5 ton [5000 kg].
Capacity range of the RMLHC Hand-geared trolley models is ½ ton [500 kg] to 5 ton [5000 kg].
Table 4. RMLH and RMLHC Trolley Specifications
Models Beam Flange Width
Range
inch [mm]
Maximum
Capacity
lbs. [kg]
Min. radius Curve
ft [m]
Weight
lbs. [kg]
RMLH-500
RMLHC-500
1.96 – 8.0 [50 – 203] 1100 [500] 3.28 [1] 46.2 [21.0]
RMLH-1000
RMLHC-1000
2.52 – 12.0 [64 – 305] 2200 [1000] 3.28 [1] 64.5 [29.3]
RMLH-2000
RMLHC-2000
3.46 – 12.0 [88 – 305] 4400 [2000] 4.92 [1.5] 113.3 [51.5]
RMLH-5000
RMLHC-5000
4.49 – 12.0 [114 – 305] 11000 [5000] 6.56 [2] 210.1 [95.5]
4 HANDLING & STORAGE
(Also see ‘Do’s and Don'ts’)
Do not allow the equipment to fall.
Do not stack these items of equipment on top of each other.
Handle the equipment by its structure or in its original packaging.
5 DO’S AND DON'TS
5.1 DO’S:
5.1.1 General
Read the manual carefully and always follow its recommendations. Only use "original parts" when repairing
or maintenance. Keep this instruction manual near the equipment and readily available to the operator and
the maintenance mechanic at all times.
