GE P&W E-Series Reverse Osmosis - E4 LE 60 Hz User Manual
Page 2

Page 2
FS1144EN
Table 2: Materials of Construction
Frame
Painted Carbon Steel
Membrane Elements
AK4040TM
Membrane Housing
Stainless Steel
Inlet Plumbing
Schedule 80 PVC
High Pressure Plumbing Reinforced rubber hose
Permeate/Concentrate
Tubing
Polyethylene, NSF approved
Control Enclosure
NEMA 1
Motor Starters
NEMA 4X
Cartridge Filter
RO,Save, 1 micron
Table 3: Pump and Motor
Pump Manufacturer Tonkaflo
Pump Type
Multi-stage, centrifugal
Materials
SS shell/housing, Noryl* internals
Castings
SS inlet/discharge
Motor
3-phase, TEFC, 208-230/460 VAC
Table 4: E4-LE Specifications - 60 Hz
Model
E4-2200
E4-4400
E4-6600
E4-8800
E4-11000
E4-13200
ECN
DLX
1230850
1230852
1230855
1230856
1230859
1230860
1230863
1230864
1230867
1230868
1230871
1230871
Flow Specifications
Recovery Range:
Permeate Rate:
gpm (m
3
/h)
Concentrate Rate:
gpm (m
3
/h)
50-75%
1.5 (0.3)
1.5-0.5 (0.3-0.1)
50-75%
3 (0.7)
3.0-1.0 (0.7-0.2)
50-75%
4.5 (1.0)
4.5-1.5 (1-0.3)
50-75%
6 (1.4)
6.0-2.0 (1.4-0.5)
50-75%
7.5 (1.7)
7.5-2.5 (1.7-0.6)
50-75%
9 (2.1)
9.0-3.0 (2.1-0.7)
Pump and Motor
Pump Model
SS1809X
SS1809X
SS1809X
SS1809X
SS1812X
SS1812X
Motor: HP (KW)
1.5 (1.1)
1.5 (1.1)
1.5 (1.1)
1.5 (1.1)
2 (1.5)
2 (1.5)
Membrane Elements
Quantity
Array
1
1
2
1-1
3
1-1-1
4
1-1-1-1
5
2-1-1-1
6
2-2-1-1
Connections
Inlet: inch (cm)
Permeate: inch (cm)
Concentrate: inch (cm)
0.75 (1.9)
0.5 (1.3)
0.5 (1.3)
0.75 (1.9)
0.5 (1.3)
0.5 (1.3)
0.75 (1.9)
0.5 (1.3)
0.5 (1.3)
0.75 (1.9)
0.75 (1.9)
0.75 (1.9)
0.75 (1.9)
0.75 (1.9)
0.75 (1.9)
0.75 (1.9)
0.75 (1.9)
0.75 (1.9)
Dimensions & Weights
Height: inch (cm)
Width: inch (cm)
Depth: inch (cm)
Shipping Weight
Estimate: lb (kg)
50 (127)
30 (76)
20 (51)
170 (77)
50 (127)
30 (76)
20 (51)
185 (83)
55 (139)
30 (76)
20 (51)
215 (98)
55 (139)
30 (76)
26 (66)
235 (107)
60 (152)
30 (76)
26 (66)
325 (147)
60 (152)
30 (76)
26 (66)
345 (156)
