Page 2 FS1600EN
Table 1: Standard Instrumentation
Flow Permeate, concentrate
Conductivity Feed, permeate
pH Feed
Pressure Indicators Primary, permeate, concen-
trate pump discharge
Pressure Switch Permeate, concentrate
Pressure Transmitter Pre-filter, post-filter, primary,
final, permeate
final
Table 2: Major Component Manufacturers
Equipment Manufacturer
Cartridge Filter GE
Membrane Element GE
High Pressure Pump GE Tonkaflo
Cartridge filter housing Filtrek
Membrane Housing Codeline
Flow Measurement Rosemount
Conductivity, pH Rosemount
Pressure Transmitters Rosemount
PLC Components Allen Bradley
Valves Bray
Table 3: Optional Features
Option Description
TITAN Media Filters Media filtration pretreatment with stainless steel internals and face piping
TITAN Clean-in-Place Cone-bottom HDPE tank with painted carbon steel stand and CIP pump for bank-by-
bank cleaning
Chemical Feed Systems Electronic metering pump for chemical pretreatment
Motor Starters Motor starters for CIP pumps, shipped loose for field installation
OSMO TITAN Models
MODEL TITAN-36 TITAN-72 TITAN-90 TITAN-144 TITAN-180
Permeate rate:
130 gpm
260 gpm,
130 gpm per train
325 gpm two train,
166 gpm two pass
520 gpm,
260 gpm per train
650 gpm two train,
332 gpm two pass
Concentrate Rate:
43 gpm
86 gpm,
43 gpm per train
109 gpm two train,
65 gpm two pass
174 gpm,
87 gpm per train
217 gpm two train,
130 gpm two pass
Feed Rate: 173 gpm 346 gpm,
173 gpm per train
433 gpm two train,
217 gpm two pass
694 gpm,
347 gpm per train
867 gpm two train,
461 gpm two pass
Pumps and Motors
Manufacturer:
Model:
Quantity:
Motor HP and type: Tonkaflo
AS22512
1
50 HP TEFC
Tonkaflo
AS22512
2
50 HP TEFC
Tonkaflo
AS40407/AS22512
1/1
60 HP/50 HP TEFC
Tonkaflo
AS40409
2
75 HP TEFC
Tonkaflo
AS40407/AS40409
2/1
2x60 HP/75 HP TEFC
Membrane Elements and Housings
Membranes quantity:
Banking Arrangement: 36
4  2
72
4  2, 4  2
90
6  3, 4  2
144
8  4, 8  4
180
12  6, 8  4
Cartridge Filtration
Cartridge Filter:
Filter Quantity: RO.Zs01-40XK
12
RO.Zs01-40XK
24
RO.Zs01-40XK
31
RO.Zs01-40XK
50
RO.Zs01-40XK
57
Installation and Utility Requirements
Inlet:
Permeate:
Concentrate:
Inlet Water Pressure:
Air Pressure:
Drain to be Sized for:
Power:
Control Circuit: 3.0-inch flange
3.0-inch flange
1.5-inch flange
30 psig min.
100 psig, oil-free
173 gpm
460 VAC, 3-phase, 60Hz
120 VAC, 1-phase, 60Hz
2x3.0-inch flange
2x3.0-inch flange
2x1.5-inch flange
30 psig min.
100 psig, oil-free
346 gpm
460 VAC, 3-phase,60Hz
120 VAC, 1-phase, 60Hz
4.0-inch/3.0-inch flange
2x3.0-inch flange
2.0-inch/1.5-inch flange
30 psig min.
100 psig, oil-free
433 gpm
460 VAC, 3-phase, 60Hz
120 VAC, 1-phase, 60Hz
2x4.0-inch flange
2x4.0-inch flange
2x2.0-inch flange
30 psig min.
100 psig, oil-free
694 gpm
460 VAC, 3-phase, 60Hz
120 VAC, 1-phase, 60Hz
6.0-inch/4.0-inch flange
2x4.0-inch flange
3.0-inch/2.0-inch flange
30 psig min.
100 psig, oil-free
867 gpm
460 VAC, 3-phase,60Hz
120 VAC, 1-phase, 60Hz
Skid
Height:
Width:
Length:
Shipping Weight:
Operating Weight: 101.7”
48”
309”
6,500LB (2,950Kg)
8,900LB (4,037Kg)
101.7”
72”
309”
11,300LB (5,126Kg)
16,300LB (7,394Kg)
102.7”
84”
309”
12,800LB (5,806Kg)
18,900LB (8,573Kg)
102.5”
92”
309”
16,200LB (7,350Kg)
25,200LB (11,430Kg)
105.6”
92”
460”
21,200LB (9,616Kg)
32,700LB (14,832Kg)
