Membrane elements and housings, Cartridge filtration, Ge pro-anz models – GE P&W PRO ANZ Series 50 Hz User Manual
Page 2: Installation and utility requirements, Skid
AP-FSpwPRO_ANZ_Series_50Hz_EN
Page 2
Membrane Elements and Housings
Membrane model............................................................... AG8040F
Style ............................................................ Spiral-wound elements
Membrane manufacturer ............................................................GE
Membrane type .................................................... TFC (Polyamide)
Average membrane flux
1
.............................. 28 lmh (16.4 gfd)
Membrane rejection .................................................... 99.0-99.6%
Housing manufacturer .......................... Wave Cyber or Equal
Housing material and rating ....................FRP, 300psi ASME
2
Cartridge Filtration
Housing model ........................................ 7 Rounds, 102cm (40“)
Housing material .................................................................... 316 SS
Cartridge filter ....................... 1-micron nominal, ROsave.Z*s
1
Flux can be reduced to 25.5 lmh (15 gfd) by using 400sqft
elements. Rated flow can be further reduced by up to 20%.
2
300psi housings used for 1000 TDS, 20C design. 450psi
housings used for 2500 TDS 16C
GE PRO-ANZ Models
MODEL
PRO-11-ANZ-50 PRO-23-ANZ-50 PRO-34-ANZ-50
PRO-45-ANZ-50
PRO-68-ANZ-50 PRO-102-ANZ-50
Permeate rate:
2
Concentrate Rate:
Feed Rate:
11.4 m
3
/hr
3.8 m
3
/hr
15.1 m
3
/hr
22.7 m
3
/hr
7.5 m
3
/hr
30.2 m
3
/hr
34.1 m
3
/hr
11.4 m
3
/hr
45.4 m
3
/hr
45.4 m
3
/hr
14.9 m
3
/hr
60.4 m
3
/hr
68.1 m
3
/hr
22.7 m
3
/hr
90.8 m
3
/hr
102.2 m
3
/hr
34.1 m
3
/hr
136.3 m
3
/hr
Pumps and Motors – Up to 1000 mg/L Feed TDS and 20C water temperature design
Manufacturer:
Model
Quantity:
Motor HP:
Design Flow Rate:
Design boost pressure:
Grundfos
CRN 15-14 A-FGJ-G-
E-HQQE
1
11 kW
18.2 m
3
/hr
15.0 bar
Grundfos
CRN 32-9-2 A-G-G-E-
HQQE
1
18.5 kW
32.4 m
3
/hr
12.3 bar
Grundfos
CRN 45-7-2 A-G-G-E-
HQQE
1
30 kW
45.4 m
3
/hr
13.5 bar
Grundfos
CRN 64-6-2 A-G-G-E-
HQQE
1
30 kW
64.9 m
3
/hr
12.3 bar
Grundfos
CRN 45-7-2 A-G-G-E-
HQQE
2
2 x 30 kW
90.8 m
3
/hr
13.5 bar
Grundfos
CRN 64-6 A-G-G-E-
HQQE
2
2 x 37 kW
136.3 m
3
/hr
13.4 bar
Pumps and Motors – Up to 2500 mg/L Feed TDS and 16C water temperature design
Manufacturer:
Model
Quantity:
Motor HP:
Design Flow Rate:
Design boost pressure:
Grundfos
CRN 15-17 A-FGJ-G-
E-HQQE
1
15 kW TEFC
18.6 m
3
/hr
18.0 bar
Grundfos
CRN 32-13-2 A-G-G-E-
HQQE
1
30 kW TEFC
33.2 m
3
/hr
18.0 bar
Grundfos
CRN 45-9 A-G-G-E-
HQQE
1
37 kW TEFC
46.5 m
3
/hr
18.0 bar
Grundfos
CRN 64-8-1 A-G-G-E-
HQQE
1
45 kW TEFC
64.6 m
3
/hr
18.0 bar
Grundfos
CRN 45-9 A-G-G-E-
HQQE
2
2 x 37 kW TEFC
91.0 m
3
/hr
18.0 bar
Grundfos
CRN 64-8-1 A-G-G-E-
HQQE
2
45 kW TEFC
136.0 m
3
/hr
18.0 bar
Membrane Elements and Housings
Membranes quantity:
Memb. housing style:
Banking Arrangement:
12
4 element long, 4 port
1
1
1
24
4 element long, 4 port
3
2
1
36
6 element long, 4 port
3
2
1
48
4 element long, 4 port
6
4
2
72
6 element long, 4 port
6
4
2
108
6 element long, 4 port
9
6
3
Cartridge Filtration
Cartridge Filter:
Filter Length:
Filter Quantity:
RO.Zs01-40
102 cm (40”)
7 per housing
7/change out
RO.Zs01-40
102 cm (40”)
7 per housing
7/change out
RO.Zs01-40
102 cm (40”)
7 per housing
14/change out
RO.Zs01-40
102 cm (40”)
7 per housing
14/change out
RO.Zs01-40
102 cm (40”)
7 per housing
21/change out
RO.Zs01-40
102 cm (40”)
7 per housing
28/change out
Installation and Utility Requirements
Inlet:
Permeate:
Concentrate:
Inlet Water Pressure:
Air Pressure:
Drain to be Sized for:
Power:
Control Circuit:
ANSI 2" flange
ANSI 2" flange
ANSI 1.5" flange
2 bar min.
6.9 bar, oil-free
15.1 m
3
/hr
380 VAC, 3-phase, 50Hz
220 VAC, 1-phase, 50Hz
ANSI 3" flange
ANSI 3" flange
ANSI 1.5" flange
2 bar min.
6.9 bar, oil-free
30.2 m
3
/hr
380 VAC, 3-phase, 50Hz
220 VAC, 1-phase, 50Hz
ANSI 3" flange
ANSI 3" flange
ANSI 1.5" flange
2 bar min.
6.2 bar, oil-free
45.4 m
3
/hr
380 VAC, 3-phase, 50Hz
220 VAC, 1-phase, 50Hz
ANSI 4" flange
ANSI 3" flange
ANSI 2" flange
2 bar min.
6.2 bar, oil-free
60.4 m
3
/hr
380 VAC, 3-phase, 50Hz
220 VAC, 1-phase, 50Hz
ANSI 4" flange
ANSI 4" flange
ANSI 2" flange
2 bar min.
6.9 bar, oil-free
90.8 m
3
/hr
380 VAC, 3-phase, 50Hz
220 VAC, 1-phase, 50Hz
ANSI 6" flange
ANSI 4" flange
ANSI 3" flange
2 bar min.
6.9 bar, oil-free
136.3 m
3
/hr
380 VAC, 3-phase, 50Hz
220 VAC, 1-phase, 50Hz
Skid
Approx.Height:
Approx. Width:
Approx.Depth:
Approx. Shipping
Weight :
2000 mm
800 mm
4900 mm
1543 kg
2200 mm
900 mm
5050 mm
2132 kg
2240 mm
950 mm
6850 mm
2722 kg
2240 mm
1250 mm
5200 mm
3085 kg
2420 mm
1400 mm
6950 mm
4490 kg
2475 mm
1850 mm
7080 mm
6124 kg
2
Maximum permeate rate listed at design temperature. Permeate rate can be reduced by up to 20%
