Page 2 Fact Sheet
Material of Construction
Welded Frame: Painted Carbon Steel
Dilute Piping: PPL
Concentrate Piping: PVC
Flanges:
DIN
DC Drive: IP55
Control Panel: IP55
Control Panel Power: 24VDC
E-Cell Standard Systems
Model GEMK3-1 EU GEMK3-3 EU GEMK3-6 EU GEMK3-9 EU GEMK3-12 EU
General Information
Number of Stacks 1 2 - 3 4 - 6 6 – 9 10 - 12
Type of stack MK-3 MK-3 MK-3 MK-3 MK-3
Flow Rates
Product Flow Nominal 3.4 m 3 /h 10.2 m 3 /h 20.4 m 3 /h 30.6 m 3 /h 40.8 m 3 /h
Product Flow Range
2.3-4.5 m 3 /h
10-20 gpm
6.8-13.6 m 3 /h
30-60 gpm
13.6-27.3 m 3 /h
60-120 gpm
20.4-40.9 m 3 /h
90-180 gpm
27.3-54.5 m 3 /h
120-240 gpm
Concentrate Outlet Flow
(Depends on Recovery & Product
Flow)
3.4-5.7 lpm
0.91-1.5 gpm
11.0-17.8 lpm
2.9-4.7 gpm
22.0-35.6 lpm
5.8-9.4 gpm
33.3-53.4 lpm
8.8-14.1 gpm
44.3-71.2 lpm
11.7-18.8 gpm
Electrode Outlet Flow
1.3 lpm
0.35 gpm
4.0 lpm
1.05 gpm
7.9 lpm
2.10 gpm
11.9 lpm
3.15 gpm
15.9 lpm
4.2 gpm
Dimensions
Overall System Dimensions
(Width x Length x Height) 0.9mx1.4mx1.8m
36”x54”x72”
1.2mx2.2mx2.1m
46”x86”x84”
1.2mx2.7mx2.1m
46”x107”x84”
1.2mx3.4mx2.1m
46”x132”x84”
1.2mx3.7mx2.1m
46”x146”x84”
Inlet Piping DN25 DN50 DN80 DN100 DN100
Product Outlet Piping DN25 DN50 DN80 DN100 DN100
Rinse Outlet Piping DN25 DN50 DN80 DN100 DN100
Electrode Outlet Piping DN15 DN15 DN15 DN15 DN15
Concentrate Outlet Piping DN15 DN15 DN20 DN25 DN40
All piping sizes are provided for nominal flow rates at 90% recovery.
Shipping Weight
454 kg
1000 lbs
1134 kg
2500 lbs
1588 kg
3500 lbs
1950 kg
4300 lbs
2268 kg
5000 lbs
Electrical
Maximum Output @ 300VDC 5.2Amps 15.6Amps 31.2Amps 46.8Amps 62.4Amps
Connection Requirement 3.5 KVA 8 KVA 15 KVA 22 KVA 29 KVA
Typical Power Consumption 0.13 – 0.26 kWh/m 3 (0.5 – 1.0 kWh/1000gal )
Standard Options:
1. Premium Model – flow & pressure transmitters, ability to connect to SCADA system.
2. Premium Model Option – removal of PLC & HMI, all wiring terminated at a IP55 Junction Box
Performance, flow rate per stack, recovery and power consumption are dependent on inlet feed water quality and temperature.
An E-Calc projection must be completed for proper system design & for any performance guarantee to be provided. Patents Pending.
