FS1016EN
Operating Parameters
Design Feed TDS
35,000 ppm NaCl
Maximum Recovery
45%
Nominal Rejection
95-98%
Operating Temperature
1.6 to 29.4ºC (35 to
85ºF)
Minimum Inlet Pressure
2 Bar (30 psig)
Design Temperature
25ºC (77ºF)
Instrumentation
Flow Meters ................... Permeate, concentrate, low
pressure (LP) ERD inlet, high
pressure (HP) ERD outlet
Conductivity .................. Permeate
pH ...................................... Feed
Pressure .......................... Pre-filter, post-filter, primary,
final, permeate, concentrate,
LP ERD inlet, LP ERD outlet,
HP ERD inlet, HP ERD outlet
(PRE Feature= Primary, Final
transmitter)
Pressure Switches ...... Feed, permeate, concen-
trate, primary
Instrument Center ..... Thornton 770 MAX
Materials of Construction
Frame
Painted Carbon Steel
Cartridge Filter
RO.Zs 05-40, 5-micron nomi-
nal
Cartridge Filter Housing
GRP (glass reinforced plastic)
Membrane Elements
AD-440
Membrane Housing
FRP
Low Pressure Pipe
Schedule 80 PVC
High Pressure Pipe
Duplex 2205
Enclosures
NEMA 4
Options Available
Allen Bradley control system
Multi-Media filters
Clean-in-Place (CIP) units
Chemical feed systems
Transfer pumps and storage tanks
Documentation Included
Operation and maintenance manual
Control narrative
Drawings: piping and instrumentation, electri-
cal and general dimensional
SeaPRO Models
MODEL
SeaPRO-42
SeaPRO-63
SeaPRO-84
SeaPRO-126
Permeate rate:
Concentrate Rate:
Feed Rate:
550 m
3
/day (100 gpm)
672 m
3
/day (122 gpm)
1,222 m
3
/day (222 gpm)
825 m
3
/day (150 gpm)
1,008 m
3
/day (183 gpm)
1,833 m
3
/day (333 gpm)
1,100 m
3
/day (200 gpm)
1,344 m
3
/day (224 gpm)
2,444 m
3
/day (444 gpm)
1,650 m
3
/day (300 gpm)
2,017 m
3
/day (367 gpm)
3,667 m
3
/day (667 gpm)
Pumps and Motors
Manufacturer:
Quantity:
HP Pump HP and Type:
Boost Pump HP and Type:
Fedco
2
75 kW (100 Hp) TEFC
5.6 kW (7.5 Hp) TEFC
Fedco
2
110 kW (150 Hp) TEFC
7.5 kW (10 Hp) TEFC
Fedco
2
150 kW (200 Hp) TEFC
15 kW (20 Hp) TEFC
Fedco
2
186 kW (250 Hp) TEFC
15 kW (20 Hp) TEFC
Energy Recovery Booster
Model:
Manufacturer:
Quantity:
PX-140S
ERI
1
PX-220
ERI
1
PX-140S
ERI
2
PX-140S
ERI
3
Membrane Elements and Housings
Membranes Quantity:
Memb. Housing Style:
Banking Arrangement:
42
7 element long, 4 port
6, parallel
63
7 element long, 4 port
9, parallel
84
7 element long, 4 port
12, parallel
126
7 element long, 4 port
18, parallel
Cartridge Filtration
Cartridge Filter:
Filter Length:
Filter Quantity:
RO.Zs05-40
40” (102 cm)
22 per change out
RO.Zs051-40
40” (102 cm)
54 per change out
RO.Zs05-40
40” (102 cm)
54 per change out
RO.Zs05-40
40” (102 cm)
108 per change out
