Fact Sheet Page 2
CH0000EN 0411
Materials of Construction
High-pressure piping ....... 316 Stainless Steel Sch 10
Low-pressure piping ........................................ PVC Sch 80
Frame ....................................... Painted blue carbon steel
Enclosure ...................................................................... Nema 4
Clamps/fittings ...................................................Zinc-plated
Cartridge Filtration
Housing model………………………..GE HX-0740-3.0-V316
Housing material………………………… 316 Stainless Steel
Cartridge filter……..….1-micron nominal, ROsave.Z*s
Membrane Elements and Housings
Housing material ............................................................... FRP
Housing Pressure Rating ..................................... 450 PSI
Average membrane flux ................................. 10-11 GFD
Membrane rejection ...................................... 98.0-99.0 %
Membrane Model ................................................. AG-400LF
Style ............................................... Spiral-wound elements
Manufacturer ........................................................................ GE
Membrane type ............. TFC (Polyamide) Low Fouling
GE ReNEW Models
MODEL ReNEW-18-NA ReNEW-36-NA ReNEW-54-NA ReNEW-72-NA ReNEW-90-NA ReNEW-108-NA
Permeate Rate 1 :
Concentrate Rate:
Feed Rate:
55 gpm
18 gpm
73 gpm 110 gpm
37 gpm
147 gpm
165 gpm
55 gpm
220 gpm
220 gpm
73 gpm
293 gpm
275 gpm
92 gpm
367 gpm
330 gpm
110 gpm
440 gpm
Pumps and Motors
Model:
Manufacturer:
Quantity:
Motor Power and type:
Installed Power:
Design Flow Rate:
Design boost pressure: SS8516
GE Tonkaflo
1
25 HP
39 Amps
73 gpm
250 psi
SS12512
GE Tonkaflo
1
40 HP
52 Amps
147 gpm
250 psi
SS24009
GE Tonkaflo
1
60 HP
77 Amps
220 gpm
250 psi
AS40407
GE Tonkaflo
1
60 HP
77 Amps
293 gpm
230 psi
AS40409
GE Tonkaflo
1
75 HP
96 Amps
367 gpm
250 psi
AS40409
GE Tonkaflo
1
75 HP
96 Amps
440 gpm
230 psi
Membrane Elements and Housings
Membranes Quantity:
Memb. Housing Style:
Banking Arrangement: 18
6 element long,
4 port
2  1
36
6 element long,
4 port
4  2
54
6 element long,
4 port
6  3
72
6 element long,
4 port
8  4
90
6 element long,
4 port
10  5
108
6 element long,
4 port
12
 6
Cartridge Filtration
Housing Model:
Housing Quantity:
Cartridge Filter Model:
Cartridge Filter Length:
Cartridge Filter Qtity: HX-0740-3.0-V-316
1
RO.Zs01-40XK
102 cm (40”)
7 per housing,
7/change out
HX-0740-3.0-V-316
2
RO.Zs01-40XK
102 cm (40”)
7 per housing,
14/change out
HX-0740-3.0-V-316
2
RO.Zs01-40XK
102 cm (40”)
7 per housing,
14/change out
HX-0740-3.0-V-316
3
RO.Zs01-40XK
102 cm (40”)
7 per housing,
21/change out
HX-0740-3.0-V-316
4
RO.Zs01-40XK
102 cm (40”)
7 per housing,
28/change out
HX-0740-3.0-V-316
4
RO.Zs01-40XK
102 cm (40”)
7 per housing,
28/change out
Installation and Utility Requirements
Inlet:
Permeate:
Concentrate:
Inlet Water Pressure:
Air Pressure:
Drain to be Sized for:
Power: 2.0-inch flange
1.5-inch flange
1.5-inch flange
30 psi, min.
80 psi, oil-free
73 gpm
480 VAC, 3-phase, 60Hz
3.0-inch flange
3.0-inch flange
1.5-inch flange
30 psi, min.
80 psi, oil-free
147 gpm
480 VAC, 3-phase, 60Hz
3.0-inch flange
3.0-inch flange
1.5-inch flange
30 psi, min.
80 psi, oil-free
220 gpm
480 VAC, 3-phase, 60Hz
4.0-inch flange
3.0-inch flange
2.0-inch flange
30 psi, min.
80 psi, oil-free
293 gpm
480 VAC, 3-phase, 60Hz
4.0-inch flange
4.0-inch flange
2.0-inch flange
30 psi, min.
80 psi, oil-free
367 gpm
480 VAC, 3-phase, 60Hz
6.0-inch flange
4.0-inch flange
3.0-inch flange
30 psi, min.
80 psi, oil-free
440 gpm
480 VAC, 3-phase, 60Hz
Skid
Height:
Width:
Depth:
Shipping Weight
Estimate: 90 inch
274 inch
48 inch
4500 lb
90 inch
274 inch
48 inch
5900 lb
92 inch
274 inch
48 inch
7500 lb
98 inch
274 inch
80 inch
9400 lb
104 inch
274 inch
98 inch
14000 lb
104 inch
274 inch
98 inch
16000 lb
1 At design temperature
