Peerless-AV RMI1 - Installation - Manual

1 of 4 ISSUED: 06-16-08 SHEET #: 120-9049-1
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
Installation and Assembly:
Rotational Mount Interface
Models: RMI1
Before you begin, make sure all parts shown are included with your product.
Parts may appear slightly different than illustrated.
Description Qty. Part #
A universal rotational mount 1 120-1183
B M10 x 15 mm round socket head screw 8 520-9262
C M6 x 10 mm socket pin head screw 4 520-1066
D multi-washer 4 580-1036
E 4 mm security allen wrench 1 560-1727
F 6 mm allen wrench 1 560-9716
Parts List
B C D A
E
F
Accessories
• ACC170 - Rotational Mount Adapter Plate
for Carts and Stands
