Peerless-AV MIS-ACC201 - Installation - Manual (Page 2)

ISSUED: 07-27-07 SHEET #: 124-9093-2 02-25-08 2 of 3
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-729-0307 or 708-865-8870.
1/4"
1-1
C
BY HAND, insert four M10 x 1.5 x 15 mm penta-pin screws (C) into threaded holes in the sides of ceiling arm
box (A). Leave approximately 1/4" of exposed thread as shown in detail 1.
C
1 Securely fasten mounting box (A) to support pipe
(not included) using two u-bolts (E), four flat
washers (G) and four nylock nuts (F).
G
F
E
• Installer must verify that the ceiling will safely support the combined weight of all attached equipment and
hardware.
WARNING
SUPPORT PIPE (NOT INCLUDED)
fig 1.2
DETAIL 1
fig 1.1
A
