Parts List
Part Description Quantity Part Number
A computer box 1 125-1458
B box cover 1 124-1459
C alternate support bracket 4 124-1141
D M4 X 10mm socket pin 4 520-1060
E M4 X 10mm serrated washer head socket pin screw 2 510-1060
F M5 X 10mm type-F socket pin screw 8 520-1164
G #10 x 1/2" TEK phillips screw 4 520-1320
H cable tie 6 560-9711
I 4mm security allen wrench 1 560-9646
A (1) B (1) C (4)
computer box
E (2) D (4) F (8) G (4)
M4 X 10mm serrated
washer head socket
pin screw
M4 X 10MM
socket pin
M5 X 10mm type-F
socket pin screw
#10 X 1/2" TEK
phillips screw
H (6)
cable tie
I (1)
4mm security
allen wrench
box cover alternate support bracket
