Button
There are four buttons that can be programmed through the screen editor, the
remaining keys are programmed in the ladder editor. To insert a button, click on the
icon and click it into the screen.
The button will then allocate itself to the nearest key next on the side of the screen.
Only one button can be assigned to a single key per screen.
The buttons are
binary and can
only be assigned
to a bit
The Keypress
source defaults
at the nearest
softkey (4 keys
either side of
the screen.
Switch type
However they
can be set to
another
address in the
i
Action
3
.
We can also
edit the
indicator
properties
