Menu Item
A Menu Item allows many settings and screens to be configured through one single
object.
Inside the Menu Item it is
possible to easily configure
groups of Numeric Data Items,
Text Tables, ASCII text Items,
Passwords, Screen Jumps and
also Sub-menu items.
The Sub-Menus allow more pages
of configurable data to be
displayed, allowing an operator to
make many changes from within
a single screen.
The menu object is navigated via
the soft keys or touch screen.
If the Exclusive Focus is selected
then no other objects on the
screen can be activated.
Clicking on the Configure Menu
Pages button opens the window
below.
The ‘Size’ of the Menu must be
selected when using on a Touch-
Screen
i 3
.
Menu Items can be added,
then, configured in a similar
way to how they are outside
of a Menu Object by
specifying the Control
Register, Data Format, and
Display Properties. The
only difference is that
‘Prompt Text’ is used
instead of a Legend.
Sub-Menus can also be
added, to partition the data
into different areas as
required.
