Glossary
www.bb-elec.com
www.bb-europe.com
31
Switches Reset button Hold in for 0 to 2 seconds for hardware reset
Hold in for 2 to 10 seconds for Console Mode
(Do a hardware reset or recycle power to exit
Console Mode)
Hold in for more than 10 seconds to reset to
factory defaults
Indicators Serial LED Color = Green
On = Port open
Blink = Data traffic
RJ45 Ethernet Link LED Color = Green
On = 100BaseTX
Off = 10BaseT
Blink = Data traffic
Ready LED Color = Green
Blink (once per second) = System in Normal
Mode
Off = System in Console Mode
Fiber Ethernet Link LED Off= No connection
On = 100BaseFX connection
Connectors 10BaseT/100BaseTX
Ethernet
Single RJ-45F (8 pin)
LC fiber LC connector
LC Multi-Mode fiber LC multi-mode connector
Serial one DB9M connector
one pluggable locking 5.08 mm terminal blocks
DC Power 5.08mm 3-position pluggable, lockable terminal
block
