Setup and Connections
www.bb-elec.com
www.bb-europe.com
9
Ethernet Pass-through Port
VESR321 family serial servers feature an additional RJ45 network port. This port can be used to connect
additional Ethernet devices, such as a local workstation, to the network.
.
Figure 10. Ethernet Pass-through Port
VESR321 Family Serial Server Configuration Connections
VESR321 family serial servers can be configured over the network or via a serial port.
Configuring the VESR321 Family Serial Server via the Network Connection
When configuring via the network, either Vlinx Manager software or the web interface can be
used.
Configuring with Vlinx Manager
VESR321 family serial servers can be configured over the network using Vlinx Manager running
on a PC.
To open Vlinx Manager:
1. From the Desktop, click StartProgramsB&B ElectronicsVlinx VESR Serial Server
ManagerSerial Server Manager.
